Boat Marine AIS Sart

Boat Marine AIS Sart

Short Description:

Specifications 1. Frequency range : CH87B(161.975 MHz)/CH88B(162.025 MHz); 2. Frequency error: ≤±0.5KHz; 3. Radiated Power : ≥1W; 4. Modulation spectrum :the frequency deviation from the carrier center frequency ±10KHz,the modulation sidebands ≤-20dBc; deviation from the carrier center frequency of +25KHz~+62.5KHz and -25KHz~-62.5KHz,the device modulation sidebands≤-40dBc; 5. Modulation: GMSK 6. Operation temperature: -20℃~+55℃ 7. Compass safe distance: 60 cm 8. Battery: lithium cell 9. Ope...


  • Min.Order Quantity: 1 Piece/Pieces
  • Supply Ability: 1000 Piece/Pieces per Month
  • Port: China Port
  • Payment Terms: L/C,TT,Western Union, Paypal
  • Product Detail

    Product Tags

    Specifications

    1. Frequency range : CH87B(161.975 MHz)/CH88B(162.025 MHz);
    2. Frequency error: ≤±0.5KHz;
    3. Radiated Power : ≥1W;
    4. Modulation spectrum :the frequency deviation from the carrier center frequency ±10KHz,the modulation sidebands ≤-20dBc;
    deviation from the carrier center frequency of +25KHz~+62.5KHz and -25KHz~-62.5KHz,the device modulation sidebands≤-40dBc;
    5. Modulation: GMSK
    6. Operation temperature: -20℃~+55℃
    7. Compass safe distance: 60 cm
    8. Battery: lithium cell
    9. Operation life: 96 H
    10. Storage time: 3 Years
    11. Reference: IEC61097-14(2010); IEC-60945(2002)
