Type CPT-165A Table Model Boat Magnetic Compass

Type CPT-165A Table Model Boat Magnetic Compass

Short Description:

CPT-165A Magnetic Compass is a sort of table model liquid magnetic compass. It is used for the middle and small vessels acting as steering compass. The compass is a magnetic compass class A and it is designed and manufactured on the basis of the national standard GB/T 14108-2011 (General Technical Terms of Marine Magnetic Compass Class A), its technical performance index are completely in accordance with the national standard. The product has the advantages of beautiful outline、high precisio...


  • Min.Order Quantity: 1 Piece/Pieces
  • Supply Ability: 1000 Piece/Pieces per Month
  • Port: China Port
  • Payment Terms: L/C,TT,Western Union, Paypal
  • Product Detail

    Product Tags

    CPT-165A Magnetic Compass is a sort of table model liquid magnetic compass.

    It is used for the middle and small vessels acting as steering compass.

    The compass is a magnetic compass class A and it is designed and manufactured on the basis of the national standard GB/T 14108-2011 (General Technical Terms of Marine Magnetic Compass Class A),

    its technical performance index are completely in accordance with the national standard.

    The product has the advantages of beautiful outline、high precision、convenient correcting difference、steady performance and legible lighting etc. It is the essential navigation instrument for the middle and small vessels.

    Main technical parameters

    Project

    Data

    Dial Diameter Φ165mm
    Dial graduation 0°~360° 1°for each grid
    Using temperature -25℃~60℃
    Indicating deviation     (H=35μT,T=20±3℃) ≤0.5°
    Half period(H=35μT,T=20±3℃) ≥8.62 S
    Friction deviation(H=35μT,T=20±3℃) ≤0.09°
    Main semicircle self heterodyne correcting energy 1°~45°
    Quadrant self heterodyne correcting energy 0.5°~10°
    Inclining self heterodyne correcting energy -75~+75μT
    Lighting power supply AC 220V,DC 24V
    Outline Dimension 730×326×570mm
    Diameter of mounting holes Pitchrow 270  ApertureΦ12
    weight 23kg
